Mikroinwerter HMT-1600-4T 3F Hoymiles

Product information "Photovoltaic microinverter HMT-1600-4T 3F Hoymiles"
The next-generation Hoymiles microinverter from the HMT-1600 series is designed to work with high-power PV modules. It supports a maximum output power of up to 1600 VA and a maximum DC input current of up to 14 A.

Its innovative design, featuring 4 inputs, ensures faster installation and lower costs, making the HMT-1600 series a highly economical choice.

The new Sub-1G wireless solution provides a more stable connection with the Hoymiles Gateway DTU. The intelligent S-Miles Cloud platform enables module-level monitoring as well as remote operation and maintenance.

IMPORTANT! For every installation built with Hoymiles microinverters of this series, it is essential to include a Hoymiles monitoring module. For this model, you can choose between DTU-Lite-S, DTU-Pro-S, or DTU-Wlite-S.

Key Product Features:

Supports up to 4 PV modules
Maximum efficiency of 96.5%
Input voltage range of 16 to 60 V
Ambient temperature range: -40 to +65 °C
External antenna for improved communication with DTU
Adjustable power factor
Passive cooling without a fan
No need for a traditional inverter at the end of the string

Operation and Installation:

Easy assembly and disassembly
Mounted directly under the panel
Tool-free networking
Barcode labels for device identification within the installation
LED status indicator on the housing
Communication via Sub-1G
IP67 protection rating
Dimensions: 326 x 222 x 40.6 mm

General features:
Type: Microinwerter
Communication type: Sub-1G
Weight [kg]: 5.9
Dimensions [mm]: 326 x 222 x 40.6
DC parameters:
Maximum short-circuit current per MPPT [A]: 25
Maximum PV power [W]: 540
Max. voltage [V]: 65
Min. MPPT voltage [V]: 16
Max. MPPT voltage [V]: 60
Initial feed-in voltage [V]: 22
Number of MPPT inputs: 2
Maximum current per one MPPT [A]: 14
Supported number of PV modules: 4
AC parameters:
Power [W]: 1600
Feed-in phases: 3
Max. output current [A]: 2.32
Efficeincy:
Max. efficiency [%]: 96.5
